Product1 Deep Groove Ball Bearings
Deep Groove Ball Bearings
  • Narrow Section Ball Bearings (16000, 16100)
  • Standard type
  • All
Dimensions
Bore diameter
≤ d ≤
d =
Width
≤ B ≤
B =
Outside diameter
≤ D ≤
D =
1～20/68
  • Deep Groove Ball Bearings
  • Narrow Section Ball Bearings (16000, 16100)
  • Standard type
  • All
Bearing No.
 Weight    Radius Rs min    Outside Ring Width B    Outside Diameter D    Features    Cr - Dynamic Load Rating    C0r - Static Load Rating    Bore Size d    Clearance
16030/C3
 2.6 Kg 1.100 mm 24.000 mm 225.000 mm 4200 rpm 2900 rpm Open 91.9 kN C3
16032/C3
 4.2... 1.500 mm 25.000 mm 240.000 mm 4000 rpm 2800 rpm Open 99 kN C3
16004/2RS
 0.0... 0.300 mm 8.000 mm 42.000 mm 20000... 13000 rpm Contact Seals 6.3 kN C3
16004/ZZ
 0.0... 0.300 mm 8.000 mm 42.000 mm 20000... 13000 rpm Shields 6.3 kN C3
16024/C3
 1.4 Kg 1.000 mm 19.000 mm 180.000 mm 4800 rpm 3300 rpm Open 58.8 kN C3
16026/C3
 1.9 Kg 1.100 mm 22.000 mm 200.000 mm 4700 rpm 3200 rpm Open 79.7 kN C3
16021/C3
 1.0 Kg 1.000 mm 18.000 mm 160.000 mm 5400 rpm 3800 rpm Open 51.8 kN C3
16019/C3
 0.7... 1.000 mm 16.000 mm 145.000 mm 5700 rpm 3900 rpm Open 42.7 kN C3
16020/C3
 0.7... 1.000 mm 16.000 mm 150.000 mm 5400 rpm 3800 rpm Open 43.8 kN C3
16022/C3
 1.3... 1.000 mm 19.000 mm 170.000 mm 5300 rpm 3600 rpm Open 57.4 kN C3
16028/C3
 2.0 Kg 1.100 mm 22.000 mm 210.000 mm 4400 rpm 3000 rpm Open 82.1 kN C3
16016/C3
 0.5... 0.600 mm 14.000 mm 125.000 mm 6400 rpm 4400 rpm Open 31.9 kN C3
16018/C3
 0.6... 1.000 mm 16.000 mm 140.000 mm 6100 rpm 4200 rpm Open 39.9 kN C3
16017/C3
 0.5... 0.600 mm 14.000 mm 130.000 mm 6100 rpm 4200 rpm Open 32.6 kN C3
16013/C3
 0.2... 0.600 mm 11.000 mm 100.000 mm 7300 rpm 5000 rpm Open 20.5 kN C3
16015/C3
 0.4... 0.600 mm 13.000 mm 115.000 mm 6700 rpm 4600 rpm Open 27.6 kN C3
16014/C3
 0.4... 0.600 mm 13.000 mm 110.000 mm 7200 rpm 5000 rpm Open 26.8 kN C3
16004/C3
 0.0... 0.300 mm 8.000 mm 42.000 mm 20000... 13000 rpm Open 6.3 kN C3
16012/C3
 0.2... 0.600 mm 11.000 mm 95.000 mm 7800 rpm 5400 rpm Open 19.9 kN C3
16011/C3
 0.2... 0.600 mm 11.000 mm 90.000 mm 8500 rpm 5800 rpm Open 19.4 kN C3
Bearing No.
 Weight    Radius Rs min    Outside Ring Width B    Outside Diameter D    Features    Cr - Dynamic Load Rating    C0r - Static Load Rating    Bore Size d    Clearance
16030/C3
 2.6 Kg 1.100 mm 24.000 mm 225.000 mm 4200 rpm 2900 rpm Open 91.9 kN C3
16032/C3
 4.2... 1.500 mm 25.000 mm 240.000 mm 4000 rpm 2800 rpm Open 99 kN C3
16004/2RS
 0.0... 0.300 mm 8.000 mm 42.000 mm 20000... 13000 rpm Contact Seals 6.3 kN C3
16004/ZZ
 0.0... 0.300 mm 8.000 mm 42.000 mm 20000... 13000 rpm Shields 6.3 kN C3
16024/C3
 1.4 Kg 1.000 mm 19.000 mm 180.000 mm 4800 rpm 3300 rpm Open 58.8 kN C3
16026/C3
 1.9 Kg 1.100 mm 22.000 mm 200.000 mm 4700 rpm 3200 rpm Open 79.7 kN C3
16021/C3
 1.0 Kg 1.000 mm 18.000 mm 160.000 mm 5400 rpm 3800 rpm Open 51.8 kN C3
16019/C3
 0.7... 1.000 mm 16.000 mm 145.000 mm 5700 rpm 3900 rpm Open 42.7 kN C3
16020/C3
 0.7... 1.000 mm 16.000 mm 150.000 mm 5400 rpm 3800 rpm Open 43.8 kN C3
16022/C3
 1.3... 1.000 mm 19.000 mm 170.000 mm 5300 rpm 3600 rpm Open 57.4 kN C3
16028/C3
 2.0 Kg 1.100 mm 22.000 mm 210.000 mm 4400 rpm 3000 rpm Open 82.1 kN C3
16016/C3
 0.5... 0.600 mm 14.000 mm 125.000 mm 6400 rpm 4400 rpm Open 31.9 kN C3
16018/C3
 0.6... 1.000 mm 16.000 mm 140.000 mm 6100 rpm 4200 rpm Open 39.9 kN C3
16017/C3
 0.5... 0.600 mm 14.000 mm 130.000 mm 6100 rpm 4200 rpm Open 32.6 kN C3
16013/C3
 0.2... 0.600 mm 11.000 mm 100.000 mm 7300 rpm 5000 rpm Open 20.5 kN C3
16015/C3
 0.4... 0.600 mm 13.000 mm 115.000 mm 6700 rpm 4600 rpm Open 27.6 kN C3
16014/C3
 0.4... 0.600 mm 13.000 mm 110.000 mm 7200 rpm 5000 rpm Open 26.8 kN C3
16004/C3
 0.0... 0.300 mm 8.000 mm 42.000 mm 20000... 13000 rpm Open 6.3 kN C3
16012/C3
 0.2... 0.600 mm 11.000 mm 95.000 mm 7800 rpm 5400 rpm Open 19.9 kN C3
16011/C3
 0.2... 0.600 mm 11.000 mm 90.000 mm 8500 rpm 5800 rpm Open 19.4 kN C3
 «Previous   1   2   …   3   4   Next»
Narrow Section Ball Bearings (16000, 16100)
